pyanno4rt: Python-based Advanced Numerical Nonlinear Optimization for Radiotherapy
General information
pyanno4rt is a Python package for conventional and outcome prediction model-based inverse photon and proton treatment plan optimization, including radiobiological and machine learning (ML) models for tumor control probability (TCP) and normal tissue complication probability (NTCP). It leverages state-of-the-art local and global solution methods to handle both single- and multi-objective (un)constrained optimization problems, thereby covering a number of different problem designs. To summarize roughly, the following functionality is provided:
- Import of patient data and dose information from different sources
- DICOM files (.dcm)
- MATLAB files (.mat)
- Python files (.npy, .p)
- Individual configuration and management of treatment plan instances
- Dictionary-based plan generation
- Dedicated logging channels and singleton datahubs
- Automatic input checks to preserve the integrity
- Snapshot/copycat functionality for storage and retrieval
- Multi-objective treatment plan optimization
- Dose-fluence projections
- Constant RBE projection
- Dose projection
- Fluence initialization strategies
- Data medoid initialization
- Tumor coverage initialization
- Warm start initialization
- Optimization methods
- Lexicographic method
- Weighted-sum method
- Pareto analysis
- 24-type dose-volume and outcome prediction model-based optimization component catalogue
- Local and global solvers
- Proximal algorithms provided by Proxmin
- Multi-objective algorithms provided by Pymoo
- Population-based algorithms provided by PyPop7
- Local algorithms provided by SciPy
- Dose-fluence projections
- Data-driven outcome prediction model handling
- Dataset import and preprocessing
- Automatic feature map generation
- 27-type feature catalogue for iterative (re)calculation to support model integration into optimization
- 7 customizable internal model classes (decision tree, k-nearest neighbors, logistic regression, naive Bayes, neural network, random forest, support vector machine)
- Individual preprocessing, inspection and evaluation units
- Adjustable hyperparameter tuning via sequential model-based optimization (SMBO) with robust k-fold cross-validation
- Out-of-folds prediction for generalization assessment
- External model loading via user-definable model folder paths
- Evaluation tools
- Cumulative and differential dose volume histograms (DVH)
- Dose statistics and clinical quality measures
- Graphical user interface
- Responsive PyQt5 design with easy-to-use and clear surface
- Treatment plan editor
- Workflow controls
- CT/Dose preview
- Extendable visualization suite using Matplotlib and PyQt5
- Optimization problem analysis
- Data-driven model review
- Treatment plan evaluation
- Responsive PyQt5 design with easy-to-use and clear surface
